Dimensions and Electrical Characteristics (in mm)
|
Part Number |
Dimensions |
Inductance |
RDC |
Rated Current |
Frequency |
|
|
LxWxH(mm) |
( μH ) |
Max.( Ω ) |
Max.( A ) |
Hz |
|
SPD6028S |
6.0*6.0*2.8 |
4.7~100 |
0.034~0.516 |
0.42~1.6 |
1K |
|
SPD7028S |
7.0*7.0*2.8 |
3.3~47 |
0.037~0.34 |
0.54~1.6 |
1K |
|
SPD7030S |
7.0*7.0*3.0 |
3.3~100 |
0.023~0.45 |
0.35~1.8 |
1K |
|
SPD7032S |
7.0*7.0*3.2 |
3.3~1000 |
0.023~4.78 |
0.13~1.9 |
1K |
|
SPD7045S |
7.0*7.0*4.5 |
3.3~1000 |
0.14~2.5 |
0.25~2.3 |
1K |
|
SPD10145S |
10.1*10.1*4.5 |
10~1500 |
0.036~3.4 |
0.26~2.5 |
1K |
|
SPD12555S |
12.5*12.5*5.5 |
6~1500 |
16.4~1730 |
0.29~3.6 |
1K |
|
SPD12565S |
12.5*12.5*6.5 |
2~220 |
11.7~273 |
1~10 |
1K |
|
SPD12575S |
12.5*12.5*7.5 |
1.2~220 |
5.0~258 |
1.3~13.0 |
1K |
Design according to customer requirements.
Data recorded for reference only, all to provide samples of business shall prevail.
Recorded content may be improved or changed without notice.
