Dimensions and Electrical Characteristics (in mm)
|
Part Number |
Dimensions |
Inductance |
RDC |
Rated Current |
Frequency |
|
|
LxWxH(mm) |
( μH ) |
Max.( Ω ) |
Max.( A ) |
Hz |
|
SPF063S |
6.2*5.6*3.2 |
10~68 |
0.14~0.82 |
0.42~1.0 |
2.52M |
|
SPF074S |
7.8*7.0*4.5 |
10~270 |
0.07~1.3 |
0.33~1.65 |
2.52M |
|
SPF105S |
10.0*9.0*5.0 |
10~470 |
0.06~1.5 |
0.33~2.06 |
2.52M |
|
|
|
|
|
|
|
Design according to customer requirements.
Data recorded for reference only, all to provide samples of business shall prevail.
Recorded content may be improved or changed without notice.
